High Frequency Stent Implantation Drug Coated Ultrasonic Spraying Coated System

Item No: FS1006
Frequency: 100KHz/120KHz/150KHz for Optional
Power: 1-15w
Continuous spraying Volume(max): 0.01-2ml/min
Effective spraying width: 1-5mm
Spray uniformity: ≥95%
Solution viscosity: ≤10cps
Input Voltage: 220V±10%/50-60Hz

Device Description:

High Frequency Stent Implantation Drug Coated Ultrasonic Spraying Coated System is a approach of the usage of ultrasonic technological know-how for drug and stent spraying, in most cases used in the discipline of vascular intervention therapy. This technological know-how combines the benefits of drug eluting stents and ultrasonic spraying technology, aiming to grant long-lasting drug launch and enhance the therapeutic impact of vascular diseases.

High Frequency Stent Implantation Drug Coated Ultrasonic Spraying Coated System is a kind of vascular stent with drug coating. It releases tablets to the surrounding blood vessel partitions whilst implanting blood vessels to inhibit the prevalence of vascular restenosis and proliferation. Ultrasonic spraying technology, on the different hand, makes use of ultrasonic vibration to spray a drug coating onto the floor of the stent, imparting uniform and long-lasting drug coverage.

Parameters:

1006

Process Steps :

1.Prepare the stent: Select a appropriate drug-eluting stent and make sure that the floor of the stent is smooth and free of impurities.

2.Preparation of spray agent: Select a suitable drug solution or suspension as the spray agent, which includes the necessary drug components for treatment.

3.Ultrasonic spraying: Place the bracket in the ultrasonic spraying tools and spray the spraying agent onto the floor of the bracket via ultrasonic vibration. The vibration of ultrasound can atomize the spray agent into small particles and evenly spray them onto the surface of the stent via airflow, attaining uniform drug coverage.

4.Drying and Curing: After finishing the spraying, the bracket wants to be dried and cured to make certain the steadiness and adhesion of the drug coating.

The gain of ultrasonic drug eluting stent spraying technological know-how lies in presenting uniform and long-lasting drug release, lowering the threat of vascular restenosis and proliferation. In addition, ultrasonic spraying science additionally helps to enhance the uniformity and adhesion of drug coatings, growing the reliability of therapeutic consequences
